Portable Diesel Hammer Crusher Ready Stock in Africa - Mobile Stone Crusher, 50-300tph, Low Maintenance

Customization:	Available
Type:	Hammer Crusher
Motor Type:	AC Motor

Quantity:




Inquire Add to Basket

Product Description

Basic Info.

Model NO.

PC

Motor Power

110kw

Application

Mine

Materials

All Kinds of Stones

Outlet Size

10-100mm

Inlet Size

600*600

Condition

New

Warranty

One Year Expect Wearing Parts

After-sales Service

One Year

Color

Yellow, Gray, Orange, Red, etc

Model

PC1214

Spare Part

Hammer Head

Input Size

500mm

Capacity

110t/H

Crushing Degree

First Crusher

Export to

Indonisia, Ghana, Nigeria, Algeria

Transport Package

Wooden Case or in Nude

Specification

8CUM

Trademark

SDSD

Origin

Shandong, China

HS Code

8474209000

Production Capacity

500/Year

Packaging & Delivery

Package Size

220.00cm * 280.00cm * 215.00cm

Package Gross Weight

14200.000kg

Product Description

Working principle of hammer crusher
The hammer crusher mainly relies on impact to break the material. The crushing process is roughly like this, the material enters the crusher, suffers the impact of the high-speed rotating hammer head and is broken, the broken material, obtains kinetic energy from the hammer head, rushes from the high-speed frame body baffle, screen bar, at the same time, the material colliding with each other, is broken many times, the material less than the gap of the screen bar, is discharged from the gap, the individual larger material, On the screen bar again by the hammer impact, grinding, extrusion and broken, the material is extruded from the gap by the hammer. To obtain the desired granularity of the product.
Portable Diesel Hammer Crusher Ready Stock in Africa - Mobile Stone Crusher, 50-300tph, Low Maintenance

COMPACT DESIGN

The overall design is beautiful, the hammer breaks the structural seal of the body, and solves the problem of dust pollution and ash leakage of the crushing workshop

ADJUSTABLE SIZE
The required granularity can be adjusted according to customer requirements

WEAR-RESISTANT
Working hammer, casting with new process, less wearing parts, easy maintenance

Model	Rotor dia. (mm)	lnter width (min)	Feeding size (mm)	Opening size (mm)	Capacity (t/h)	Motor power (KW)
PC0608	800	800	300	10-80	10-80	45-55
PC0810	800	1000	400	10-80	15-100	55-75
PC1010	1000	1000	500	10-80	20-120	75-90
PC1012	1000	1200	500	10-80	20-150	90-110
PC1214	1200	1400	600	10-100	30-200	110-132
PC1416	1400	1600	700	10-100	40-350	160-200
PC1418	1400	1800	700	10-100	45-400	180-220
PC1618	1600	1800	700	10-100	50-450	160*2
PC1620	1600	2000	700	10-100	50-500	180*2
PC1820	1800	2000	900	10-150	65-600	200*2
PC2020	2000	2000	1000	10-150	70-750	220*2
PC2024	2000	2400	1000	10-150	80-900	315*2
